強化絶縁

強化絶縁

CINCONは、鉄道、バッテリ駆動システム、通信、一般産業用で10W～750Wの絶縁設計を強化したDC-DCコンバータを提供しております。このようなアプリケーションにおいて、強化絶縁電源は危険な電気の防止、電気ショックリスクの低減などの精密機器の動作を保障するために重要な役割を果たしており、安全規格および規制遵守を維持する上で重要な要素でもあります。また、多様なパッケージやEMI内蔵シャーシマウントモジュールも用意しております。

18:1 Input Range

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		EC7AW18	10W	8.5~160V	5V, 12V, 15V, ±5V, ±12V, ±15V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	1.25x0.80x0.50(DIP24)		Stock	RFQ
		EC7BW18	20W	8.5~160V	5V, 12V, 15V, ±12V, ±15V, ±24V	3KVac Isolation UL62368-1 EN45545-2 EN50155 Compliant	2.00x1.00x0.40(DIP)		Stock	RFQ
NEW		ECB40W18	40W	8.5~160V	5V, 12V, 15V, 24V, 48V, 54V	3KVac Isolation UL62368-1 EN45545-2 EN50155 Compliant	2.00x1.00x0.50(DIP)		Stock	RFQ

16:1 Input Range

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		EC7AW18-ECRT/EDRT	10W	10~160V	5V, 12V, 15V, ±5V, ±12V, ±15V	3KVac Isolation EN50121-3-2/ EN45545-2 Compliant Low Inrush Current Input Reverse Polarity Protection EN50155 Class S3 / C2 Without External Capacitor EN50155 Compliant	4.00x2.14x0.80 (ECRT) 4.00x2.14x1.38 (EDRT)		Stock	RFQ
		EC7BW18-ECRT/EDRT	20W	10~160V	5V, 12V, 15V, ±12V, ±15V, ±24V	3KVac Isolation EN50121-3-2/ EN45545-2 Compliant Low Inrush Current Input Reverse Polarity Protection EN50155 Class S3 / C2 Without External Capacitor EN50155 Compliant	4.45x2.33x0.85 (ECRT) 4.45x2.33x1.43 (EDRT)		Stock	RFQ
NEW		ECB40W18-ECRT/EDRT	40W	10~160V	5V, 12V, 15V, 24V, 54V	3KVac Isolation EN50121-3-2/ EN45545-2 Compliant Low Inrush Current Input Reverse Polarity Protection EN50155 Class S3 / C2 Without External Capacitor EN50155 Compliant	5.63x2.56x0.87 (ECRT) 5.63x2.56x1.54 (EDRT)		Stock	RFQ

14:1 Input Range

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		CQB75W14	75W	12~160V	5V, 12V, 15V, 24V, 28V, 54V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
		CQB100W14	100W	12~160V	5V, 12V, 15V, 24V, 28V, 54V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
NEW		CQB150W14	150W	12~160V	5V, 12V, 15V, 24V, 28V, 54V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ

12:1 Input Range

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		CHB150W12	150W	14~160V	5V, 12V, 15V, 24V, 48V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×2.40x0.50 (Half Brick)		Stock	RFQ
		CHB200W12	200W	14~160V	12V, 15V, 24V, 48V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×2.40x0.50 (Half Brick)		Stock	RFQ
NEW		CRT100W12	100W	14.4~160V	12V, 24V, 48V	3KVac Isolation EN50121-3-2/ EN45545-2 Compliant Low Inrush Current Input Reverse Polarity Protection EN50155 Class S3 / C2 Criteria A Without External Capacitor EN50155 Compliant	5.09x2.28x1.35		Stock	RFQ

8:1 Input Range

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		CQB50W8	50W	9~75V	12V, 15V, 24V, 28V, 48V	3KVac Isolation UL62368 & CB EN45545-2 EN50155 Compliant M2 grade option	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
		CQB75W8	75W	9~75V	12V, 15V, 24V, 28V, 48V	3KVac Isolation UL62368 & CB EN45545-2 EN50155 Compliant M2 grade option	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
		CQB50W8-36SXX-CMFC(D)	50W	9.5~75V	12V, 15V, 24V, 28V, 48V	3KVac Isolation Screw Terminal Build in filter Baseplate Cooled EN45545-2 EN50155(EMC)	4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)		Stock	RFQ
		CQB75W8-36SXX-CMFC(D)	75W	9.5~75V	12V, 15V, 24V, 28V, 48V	3KVac Isolation Screw Terminal Build in filter Baseplate Cooled EN45545-2 EN50155(EMC)	4.60x2.40x1.46 (CMFC) 4.60x2.49x1.46 (CMFD)		Stock	RFQ
NEW		CQB100W8	100W	9~75V	5V, 12V, 15V, 24V, 28V, 48V, 54V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
NEW		CQB150W8	150W	9~75V	5V, 12V, 15V, 24V, 28V, 48V, 54V	3KVac Isolation UL62368-1 & CB EN45545-2 EN50155 Compliant	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ

2:1 Input Range

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		CQB75-300S	75W	180~450V	3.3V, 5V, 12V, 15V, 24V, 48V	3KVAC Isolation UL62368-1 & CB M2 grade option	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
		CQB75-300S-CMFC(D)	75W	180~450V	3.3V, 5V, 12V, 15V, 24V, 48V	3KVac Isolation Screw Terminal Build in filter EN45545-2 Baseplate Cooled	4.60x2.40x1.24 (CMFC) 4.60x2.49x1.35 (CMFD)		Stock	RFQ
		CHB100-110S	100W	66~160V	12V, 15V, 24V, 48V	3KVac Isolation EN45545-2 EN50155 Compliant	2.28×2.40x0.50 (Half Brick)		Stock	RFQ
		CQB150-300S	150W	180~425V	5V, 12V, 15V, 24V, 28V, 48V	3KVAC Isolation UL62368-1 & CB M2 grade option	2.28×1.45x0.50 (Quarter Brick)		Stock	RFQ
		CQB150-300SXX-CMFC(D)	150W	180~425V	5V, 12V, 15V, 24V, 28V, 48V	3KVac Isolation Screw Terminal Build in filter EN45545-2 Baseplate Cooled	4.60x2.40x1.26 (CMFC) 4.60x2.49x1.35 (CMFD)		Stock	RFQ
		CHB300-300S	300W	180~425V	5V, 12V, 24V, 28V, 48V	3KVAC Isolation UL60950-1 & CB M2 grade option	2.28×2.40x0.50 (Half Brick)		Stock	RFQ
		CHB300-300SXX-CMFC(D)	300W	180~425V	5V, 12V, 24V, 28V, 48V	3KVac Isolation Screw Terminal Build in filter EN45545-2 Baseplate Cooled	6.50x3.00x1.52 (CMFC) 6.50x3.09x1.57 (CMFD)		Stock	RFQ
		CFB600-300S	600W	180~425V	12V, 24V, 48V	3KVAC Isolation UL60950-1	4.60×2.40x0.50 (Full Brick)		Stock	RFQ
		CFB750-300S	750W	200~425V	12V, 15V, 24V, 28V, 36V, 48V	3KVAC Isolation	4.60×2.40x0.50 (Full Brick)		Stock	RFQ
		CFB750-300SXX-CMFD	750W	200~425V	12V, 15V, 24V, 28V, 36V, 48V	3KVac Isolation Screw Terminal Build in filter EN45545-2 Baseplate Cooled	9.45x4.33x1.65		Stock	RFQ

High Isolation 6KV

		Model	Power	Input Voltage	Output Voltage	Features	Dimensions (Inch)	Datasheet	Find stock	RFQ
		EC4AW-H6	6W	9~36V, 18~72V	5V, 12V, ±12V, ±15V	6KVdc Isolation Design Meets Reinforced Insulation EN55032 Class A 5uA Leakage Current	1.25x0.80x0.40 (DIP24)		Stock	RFQ
